Silicon carbide rod Pusher Type Sintering Furnace for advanced ceramic materials
Pusher furnaces are classified according to their design features.
Pusher furnaces are designed for the tight control of temperature and atmosphere necessary for processes with long residence times that require exact control. Our systems can safely operate in air, hydrogen, inert and most reducing gas environments. Our focus is on systems that offer the greatest operating life, lowest operating cost, and highest efficiency in your production line.
It is an ideal material for sintering, drying and annealing of advanced ceramic materials, alumina zirconia structural parts, electronic components, ceramic filters
| MAX temperature | 1350℃ |
| Working temperature | 1300℃ |
| Chamber size | L18000*W760*H280mm,also can be customized |
| Push plate size | L340*W340*H30mm |
| Rated power | 260KW |
| Heat preservation power | 140KW |
| Heating element | Silicon carbide rod |
| Heating method | horizontal heating |
1. Multi-surface heating method is adopted, and the temperature difference of the furnace can reach within ±5°C
2.Imported light insulation materials are used for heat preservation, high efficiency and 20-30% energy saving than traditional kilns
3.The production uses a special transmission mode, the system is stable, reliable, and runs smoothly which can highly improving product performance
4. Suitable for mass production, from pre-firing to product ceramic firing, the process is stable and the consistency is good.
With proven engineering knowledge and more than 20 years' experience we can provide you the right furnace solution.
We will well pack the goods based on the kinds of furnace and customer's requirement.
