Continuous Anode Material Sintering Rhk Kiln High Temperature Heat Treatment

1
MOQ
Negotiable
Price
Continuous Anode Material Sintering Rhk Kiln High Temperature Heat Treatment
Features Gallery Product Description Request A Quote
Features
Specifications
Roller Type: Silicon Carbide Rolls And High Aluminum Rolls
Heating Fuel: Nature Gas
Transfer Method  : Helical Gear Segment Transmission
Temperature Control Method: PID Automatic Control
Furnace Size: Customized
Chamber Size: Customized
OEM: Can
ODM: Can
High Light:

Sintering rhk kiln

,

Continuous Anode Material rhk kiln

,

Heat Treatment sintering kiln

Basic Infomation
Place of Origin: CHINA
Brand Name: QIANJIN
Certification: ISO9001
Model Number: GRHF
Payment & Shipping Terms
Packaging Details: plywood package
Delivery Time: 30 work days
Supply Ability: 100PCS/month
Product Description

High Temperature Heat Treatment Continuous Anode Material Sintering Roller Hearth Kiln



Roller hearth kilns equipped with silicon carbide elements have been the standard for the calcination process in cathode production for many years.



1﹑Applicable Material

Advanced ceramic materials, high-purity alumina powder, catalysts, magnetic materials, rare earth materials.



2﹑Technical Specification

Brief parameters of natural gas double-layer roller hearth kiln

Item Specification
Length of kiln 150m

Roller type

Silicon carbide rolls and high aluminum rolls

Length of preheating

32m
Length of Firing 68m
Length of Cooling zone 50m
Unit length 2.5m

Kiln width

2.9m
Height of Preheating cooling surface 1.33m
Width of preheating cooling surface 3.66m
Height of cooling surface in firing zone 2.0m
Width of cooling surface in firing zone 3.94m
Firing cycle 8-24 hours adjustable
Rated temperature 1300℃
heating fuel Nature gas
temperature difference inside the kiln ±50℃
transfer method

Helical gear segment transmission

Temperature control method PID intelligent automatic instrument control, can realize fully automatic control + whole process monitoring
The centralized electrical control system of the natural gas double-layer roller kiln can monitor the entire production process, including the combustion system of the roller kiln, the transmission system, the operation status of each layer of products in the kiln, etc.





Continuous Anode Material Sintering Rhk Kiln High Temperature Heat Treatment 0

3﹑Patent

With proven engineering knowledge and more than 20 years' experience we can provide you the right furnace solution.

Continuous Anode Material Sintering Rhk Kiln High Temperature Heat Treatment 1



4﹑Customer Case in China



The first Mobile phone fast charging graphene heat dissipation film carbonization production line

Continuous Anode Material Sintering Rhk Kiln High Temperature Heat Treatment 2

The first ITO target powder roller furnace continuous production line in china

Continuous Anode Material Sintering Rhk Kiln High Temperature Heat Treatment 3



5﹑Foreign Customer

Continuous Anode Material Sintering Rhk Kiln High Temperature Heat Treatment 4

6﹑Package and shipment

We will well pack the goods based on the kinds of furnace and customer's requirement.

Continuous Anode Material Sintering Rhk Kiln High Temperature Heat Treatment 5
