1700C Lift Furnace Programmable Controlled Bottom Loading Elevator Furnace For Alumina Zirconia Structural

1
MOQ
Negotiable
Price
1700C Lift Furnace Programmable Controlled Bottom Loading Elevator Furnace For Alumina Zirconia Structural
Features Gallery Product Description Request A Quote
Features
Specifications
Design Temperature: 1750°C
Work Temperature: 1700°C
Atmosphere: Air Or Supplementary Oxygen
Furnace Size: Customized
Heating Element: High-quality U-shaped Silicon Molybdenum Rod
Lifting Method: The Motor Drives The Screw To Rotate And Lift
Furnace Material: Imported Alumina Ceramic Fiber Material
Lifting Stroke: ≦1200mm
Heating Method: Heating Around The Furnace
OEM/ODM: Can
Highlight:

1700C Lift Furnace

,

ISO9001 Lift Furnace

,

Heat Treatment Elevator Furnace

Basic Infomation
Place of Origin: CHINA
Brand Name: QIANJIN
Certification: ISO9001
Model Number: LF
Payment & Shipping Terms
Packaging Details: plywood package
Delivery Time: 30 work days
Payment Terms: L/C, T/T
Supply Ability: 100PCS/month
Product Description

Programmable Controlled Bottom Loading Elevator Furnace For Alumina Zirconia Structural Heat Treatment

1﹑Applicable material

Qianjin Elevator Furnaces offer a stable loading system for furnaces up to 1700ºC.Elevator furnace is suitable for advanced ceramic materials, alumina zirconia structural parts, targets, ceramic substrates and other materials.

2﹑Technical specification

Design temperature 1750°C
Maximum operating temperature 1700°C
Furnace atmosphere air or supplementary oxygen
Furnace size L1800*W600*H600 mm, can be customized
Heating element high-quality U-shaped silicon molybdenum rod
Lifting method the motor drives the screw to rotate and lift
Furnace material imported alumina ceramic fiber material
Lifting stroke ≦1200mm
Heating method heating around the furnace


1700C Lift Furnace Programmable Controlled Bottom Loading Elevator Furnace For Alumina Zirconia Structural 0

3﹑Advantage

1.It can be equipped with Qianjin VOC waste gas incinerator to effectively treat the VOC gas discharged during the sintering process
2.High-quality furnace materials can greatly reduce energy consumption
3. Imported intelligent temperature control instrument with PID self-tuning function, multi-segment program programming, can program various temperature rise and heat preservation programs, and the temperature control accuracy can reach ±1°C
4. Furnace chamber sizes can be customized according to customer requirements
5. The kiln temperature range is available from 1200°C to 1700°C
6. High temperature uniformity, heating around the furnace can ensure the uniformity of furnace temperature


4﹑Patent

With proven engineering knowledge and more than 20 years' experience we can provide you the right furnace solution.

1700C Lift Furnace Programmable Controlled Bottom Loading Elevator Furnace For Alumina Zirconia Structural 1



5﹑Customer Case in China



The first Mobile phone fast charging graphene heat dissipation film carbonization production line

1700C Lift Furnace Programmable Controlled Bottom Loading Elevator Furnace For Alumina Zirconia Structural 2

The first ITO target powder roller furnace continuous production line in china

1700C Lift Furnace Programmable Controlled Bottom Loading Elevator Furnace For Alumina Zirconia Structural 3



6﹑Foreign Customer

1700C Lift Furnace Programmable Controlled Bottom Loading Elevator Furnace For Alumina Zirconia Structural 4

7﹑Package and shipment

We will well pack the goods based on the kinds of furnace and customer's requirement.

1700C Lift Furnace Programmable Controlled Bottom Loading Elevator Furnace For Alumina Zirconia Structural 5
